Smooth Aluminum Pipe Jacket

2025-05-28

The smooth aluminum pipe jacket is a metal protective material designed for pipe insulation. It has the characteristics of light weight, corrosion resistance, and easy processing. It is widely used in industrial and civil fields.

Alloy grade
1. 1060 aluminum coil
- Features: high purity (aluminum content ≥ 99.6%), smooth and delicate surface, excellent thermal conductivity, good processing performance, suitable for pipeline insulation scenes with high surface finish requirements.
- Applicable scenarios: electronic appliances, building curtain walls, pipeline insulation (smooth surface required).

2. 3003 aluminum coil
- Features: Al-Mn alloy, corrosion resistance is better than 1060, welding performance is good, suitable for chemical, power plants and other environments with high anti-rust requirements.
- Applicable scenarios: chemical plant pipeline insulation, new energy vehicle water cooling plate, heat dissipation fins.

Key parameters and specifications of smooth aluminum jacket:
- Thickness: Common thickness range: 0.3-1.0mm. Customizable: Some suppliers support 0.2mm.
- Width: Standard width: 1200mm, 2000mm. Customizable: 100-2500mm (need to be negotiated with the supplier).
- Length: Standard length: 100m. Customizable: Some suppliers support longer specifications.

Core advantages of smooth aluminum pipe jacket:
- Corrosion resistance and long life: The oxide film on the surface of the aluminum coil can resist external erosion, and the service life exceeds 20 years, far exceeding iron sheet (3-5 years).
- Lightweight and easy to process: Light weight (about 2.71kg per square meter), can be easily bent and wrapped around the pipe, reducing the difficulty and cost of construction.
- Beautiful and easy to maintain: The surface is smooth and tidy, no regular rust removal is required, and it is easy to clean.
- Environmentally friendly and recyclable: It can be recycled and reused, and 60%-70% of the cost can still be recovered after scrapping, which is in line with the concept of green development.

Application fields of smooth aluminum jacketing:
1. Industrial field
- Power plants and chemical plants: used for thermal insulation protection of desulfurization flues, steam pipes and reactors.
- Oil fields and petrochemicals: Resist salt spray corrosion in crude oil pipelines, storage tanks and other equipment to extend service life.
- Nuclear power plant: Meet high safety requirements and used for insulation and protection of nuclear reactor pipes.

2. Civil and construction
- Heating system: In the renovation of heating pipes, aluminum jacket roll reduce heat loss by about 30% and improve energy efficiency.
- Central air conditioning: Wrap air conditioning ducts to prevent condensation and improve aesthetics.
- Tank coating: Used for water tanks, cold storage and other equipment, with both insulation and moisture-proof functions.

Selection suggestions
- Preferentially choose 1060 aluminum coil: if a high-gloss surface is required and the environment is less corrosive (such as construction and electronics industries).
- Preferentially choose 3003 aluminum coil: if used in chemical plants, power plants and other scenes with high anti-rust requirements.
- Pay attention to cost control: compare quotations from different suppliers.

Smooth aluminum pipe jacket have become an ideal choice for pipeline insulation and protection due to their advantages such as corrosion resistance, light weight, easy processing and long life. Whether it is industrial pipelines or civil facilities, its performance and economy are significantly better than traditional materials and meet the needs of sustainable development.
