The main alloying element of 5052 aluminum strip is magnesium, which has good formability. It has good corrosion resistance and is easy to weld and cold work. 5052 H32 aluminum is the most commonly used 5052 aluminum plate state, which represents a product with a hardness of 1/4 hardness. 5052 has strong corrosion resistance, good surface oxidation, bending resistance, and is not easy to crack. Whether it is used as an aluminum plate, aluminum coil, or aluminum strip, it is a typical alloy material.

Specification of 5052 Aluminum Strip:

5052 Aluminum Strip Typical Temper

5052 H32 Aluminum Strip

H32 Temper: This indicates that the aluminum has been strain-hardened and stabilized by low-temperature heating. It is then artificially aged to a stable condition. The H32 temper provides a good balance of strength and formability.

5052 H34 Aluminum Strip

H34 Temper: Similar to H32, it has undergone strain-hardening and has been stabilized. The H34 temper is achieved by controlling the amount of strain and the rate of cooling during the aging process. This temper provides increased strength compared to H32.

5052 H36 Aluminum Strip

H36 Temper: This temper is achieved by a slightly different process than H32 and H34. It involves a greater amount of strain hardening and a different stabilization treatment. The H36 temper offers higher strength compared to H34.

5052 H38 Aluminum Strip

H38 Temper: This is a high-strength temper achieved by a combination of strain hardening and aging. The H38 temper provides the highest strength among the mentioned temper conditions.

Chemical Composition of 5005 Aluminium Strip

5052 Aluminum Strip Mechanical Properties

Tensile Strength: 33, 000 psi

Yield Strength: 28, 000 psi

Elongation: 12%

Hardness (Brinell): 60 HB

5052 Aluminum Strip Physical Properties

Density: 0.0975 lb/in³

Melting Point: 1, 220°F

Thermal Conductivity: 138 W/(m·K)

5052 Aluminum Strip Surface Finish

- Mill Finish: Commonly used for general applications.

- Anodized: Enhances corrosion resistance; used in marine environments.

- Painted/Coated: Provides additional protection; used in architectural applications.

Advantages of 5052 Aluminum Strip:

- Corrosion Resistance

5052 aluminum has excellent corrosion resistance, making it suitable for use in marine environments and other applications where exposure to moisture or harsh weather conditions is a concern.

- Formability

This alloy is highly formable, allowing it to be easily shaped into different profiles. It can be rolled, stamped, drawn, or bent without losing its properties.

- Weldability

5052 aluminum has good weldability, making it easy to join using various welding techniques. This property is essential in manufacturing processes where components need to be fused together.

- High Fatigue Strength

The alloy exhibits good fatigue strength, which is beneficial in applications where the material undergoes cyclic loading, such as in structural components.

- Surface Finish

5052 aluminum can achieve a smooth and attractive surface finish, making it suitable for applications where aesthetics are important.

5052 Aluminum Strip Common Applications

- Marine Components: Boat hulls, decks, and components due to corrosion resistance.

- Architectural Panels: Anodized or coated strips for building facades.

- Automotive Parts: Body panels, fuel tanks, and components.

- Electrical Enclosures: Due to its electrical conductivity.

Aluminum products of Haomei Al. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
