Aluminium 5083 H111 VS H116 VS H112 VS H321

2024-11-13

Aluminium alloy 5083 is a marine grade aluminum alloy, popular for its excellent corrosion resistance, high strength and good weldability. 5083 aluminium alloy is widely used in various fields, especially in shipbuilding, including maritime vessels, automobiles, aircraft weldments, subway light rail, pressure vessels resistant to strict fire protection (e.g., liquid tankers, refrigerated trucks, refrigerated containers), refrigeration installations, drilling equipment, transportation equipment, missile parts, and armor. The different heat treatment states (H111, H116, H112, H321) of aluminium 5083 indicate their different processing and mechanical properties.

The following is a detailed comparison of aluminium 5083 h111, 5083 h116, 5083 h112 and 5083 h321:
1. 5083-H111.
- Description: This state is a strain-hardened aluminum alloy, but has no specific mechanical properties required.
- Properties: Typically medium strength and good ductility, suitable for some applications where strength is not required.

2. 5083-H116.
- Description: This state is designed for marine applications and undergoes a more rigorous testing process.
- Performance: Provides higher strength and better resistance to stress corrosion cracking and is typically used in shipbuilding, offshore structures and other applications exposed to seawater.

3. 5083-H112.
- Description: Similar to H111 but with specific mechanical property requirements.
- Performance: The mechanical properties of H112 are generally superior to those of H111 and are used in applications where high strength is required but where the specific requirements of H116 are not needed.

4. 5083-H321.
- Description: This state is a stabilized aluminum alloy typically used in high stress applications.
- Performance: H321 is treated to provide better resistance to stress corrosion cracking and is suitable for use in marine and other environments where strength and durability are important.

Key differences are summarized:
- H111: General purpose, moderate strength, no specific mechanical properties.
- H116: High strength, good corrosion resistance, designed for marine applications.
- H112: Better mechanical properties than H111, suitable for applications requiring higher strength.
- H321: Stabilized for excellent resistance to stress corrosion cracking and suitable for high stress applications.

Specific application requirements such as strength, corrosion resistance and weldability need to be considered when selecting the appropriate condition. In marine environments, H116 is often preferred because its enhanced properties are better suited to demanding conditions, while H111 may be suitable for less demanding applications.
