5005 Aluminum Sheet

Properties Strength Packaging and Delivery

Properties of 5005 Aluminum Sheet/Coil

5005 aluminum sheet/coil of HAOMEI Al. is certificated to ASTM, EN as well as JIS, etc. and it can be cut to size at customers’ need. Mg is the principal element in the 5005 aluminum sheet/coil and when it used as main alloying element or combined with Mn, high strength and no-heat treatable properties can be realized. 5005 aluminum sheet/coil of HAOMEI Al. has many tempers available, such as 5005-H12, 5005-H14, 5005-H16, 5005-H18,5005-H22, 5005-H24, 5005-H32, 5005-H34, 5005-H36, 5005-H38, etc.

Elements

Others

Content

0.3

0.7

0.2

0.5-1.1

0.1

0.25

0.15

Remain

Alloy
Temper

Specified

thickness

Tensile
strength

Yield
strength

Elongation

(MPa)

(%)

5005-H34

5005-H24

0.2~0.63mm

138.179

Min104

min 3

0.63~1.2mm

min 4

1.2~6.3mm

min 5

6.3~50mm

min 8

5005-H32 or 5005-H22

0.2~600mm

118-158

Min83

min 3

5005-H14

145-186

min118

min1

Features and Applications of 5005 Aluminum Sheet/Coil

The main content of 5005 aluminum sheet/coil is Fe, Mg and Si, thus, it has good weld-ability and resistance to correction (especially when anodized), which resulting in suitable for marine applications. 5005 aluminum sheet/coil is also a non-heat treatable alloy and it can be strengthened (hardened) by cold working. However, hot working should not normally be necessary. Besides, it scores well in formability, especially in softer tempers. The machinability of 5005 aluminum sheet/coil is generally fairly poor. 5005-H34 and 5003-H38 can be machined, but with much more difficult than many other aluminum alloys.

Strength of Haomei Al.

Technologies:Top polishing technology guarantees good luster and smooth surface.
Markets:Obtain market sharing all over the world.
Equipment:Advanced cutting line to provide a wide range of specifications.
Production capacity:200, 000 tons annually in total.
Employees:Over 25 sale persons to provide good service for customers.
Responsibility: Engaged in charity donation and provide eco-friendly products.

Packaging and Delivery of Haomei Al.

Aluminum products of Haomei Al. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
